Dura Start Battery (Thailand) Co., Ltd.
Quiet power, in sodium.
Sodium-ion start-stop batteries for motorcycles, composed with an intelligent battery management system.
The essentials
Everything a start requires. Nothing it doesn't.
The DTZ5S, in four numbers from its data sheet.
12VNominal voltage
80ACold cranking amps
3000+Cycles at 80% DOD
454 gWeight · IP67
Craft
An intelligence within.
Each pack pairs sodium-ion cells with a battery management system that monitors, estimates and protects.
- Discharge managementHow energy leaves the pack.
- Thermal managementAttention to temperature.
- Fault alarm & protectionOver-charge, over-discharge, over-current, short circuit.
- CommunicationReports pack status.
- State of chargeAh integration, OCV correction, Kalman filtering.
From the Dura Start company profile. Copy pending client approval.
Specification
DTZ5S, in full.
Reproduced from the DuraStart DTZ5S data sheet.
Electrical 7 values
- Nominal voltage
- 12V
- Nominal capacity
- 1700mAh
- Energy
- 20.4 Wh
- Internal resistance
- ≤35mΩ
- Cycle life
- >3000 @80% DOD
- Self-discharge
- ≤5%/month @25°C
- Cold cranking amps
- 80A
Charge 5 values
- Charge voltage
- 14.8V ±0.2V
- Max. charge current
- 5C @25°C
- Charge current
- 0.5C @15–45°C
0.2C @10–15°C
0.1C @0–10°C - Charge mode
- CC/CV @15–40°C
- Charge temperature
- 0–45°C
Discharge 5 values
- Cut-off voltage
- 6V
- Recommended current
- 0.5C @25°C
- Max. continuous
- 40C @0–45°C
- Instant
- 70C (≤2s) @25°C
- Discharge temperature
- −40–60°C
Form 5 values
- Case
- ABS
- Dimensions
- 113 × 69 × 86 mm ±2
- Weight
- 454 g
- Protection
- IP67
- Humidity
- 60 ±25% RH
Conditions as stated on the data sheet.
Download the data sheet ↓The collection
One introduced. Three to follow.
Further models are presented once their data sheets are approved.
DTZ6V
Forthcoming
DTZ7S
Forthcoming
DTZ7V
ForthcomingThe house
Dura Start Battery (Thailand) Co., Ltd. specialises in sodium battery technology for vehicle start-stop systems, serving Thailand and Southeast Asia.
To drive a cleaner automotive future where every journey begins with sustainable, abundant energy.Our mission
To lead the future of motorcycle energy in Thailand, becoming the national standard for high-performance start-stop power.Our vision
ISO 9001ISO 14000IEC 62133-2UN 38.3IP67RoHSREACHMSDSPb-free
Marks as shown on the DTZ5S data sheet.
